01 / Overview
Ruggiero di Lauria-class battleship
Category
Country
Prime contractor
Production
1881–1891
Quantity
3
Operators
02 / Specs & Design
◎Identification7MOD.7
- Hull ClassificationIronclad
- Ship TypeBattleship
- Builder / ShipyardRegio Cantiere di Castellammare di Stabia, Venetian Arsenal, Arsenale di La Spezia
- Laid Down1881
- Commissioned1888
- Ships in Class3
- In ServiceNo
◈Displacement2MOD.2
- Light Displacement9,886 t
- Full Load Displacement10,997 t
▣Dimensions4MOD.4
- Length (overall)105.9 m
- Length (waterline)100 m
- Beam19.84 m
- Draft8.33 m
◇Complement1MOD.1
- Total Complement508
◆Propulsion9MOD.9
- PropulsionSteam Turbine
- Arrangement (CODAG/COGAG…)2 × marine steam engines, 8 × fire-tube boilers, 2 × screw propellers
- Number of Engines2
- Shaft Power7,815 kW
- Shafts / Screws2
- Top Speed17 kn
- Cruise Speed10 kn
- Range2,800
- Nuclear-PoweredNo
▤Gun Armament4MOD.4
- Main Gun4 × 432 mm 27-cal. breech-loading guns
- Main Gun Calibre432 mm
- Main Gun Count4
- Secondary Guns2 × 152 mm 32-cal. guns
⬢Missile Armament3MOD.3
▲Underwater Warfare4MOD.4
- Torpedo Tubes4
- ASW CapabilityNo
- Hull-Mounted SonarNo
- Towed Array SonarNo
◎Aviation3MOD.3
◈Sensors & Combat Systems3MOD.3
▣Survivability5MOD.5
- CBRN CitadelNo
- DegaussingNo
- Hull MaterialIron
- Stealth ShapingNo
- Automated Damage ControlNo
◇Fleet Status8MOD.8
- Completed3
- Active0
- Under Construction0
- Planned3
- Cancelled0
- Lost1
- Retired3
- Preserved0
◆Armour3MOD.3
- ArmourBelt: 451 mm, Deck: 76 mm, Barbettes: 361 mm, Conning tower: 249 mm
- Belt Armour451 mm
- Deck Armour76 mm
03 / History
SERVICE LIFESPANRetired
- 1881Production started
- 1891Production ended
- 1896Entered service
- 1914First deployment: World War I
145
years in service
10
years in production
3
units produced
0
countries operating
ⓘ The producing country no longer actively operates it. 1 countries retired it.
05 / MASS Score
Not enough weapon data to rank this category.
