Odin-class coastal defense ship
02 / Specs & Design
◎Identification6MOD.6
- Hull ClassificationCoastal defense ship
- Ship TypeCoastal defense ship
- Laid Down1893
- Commissioned1896
- Ships in Class2
- In ServiceYes
◈Displacement2MOD.2
- Light Displacement3,550 t
- Full Load Displacement3,754 t
▣Dimensions4MOD.4
- Length (overall)79 m
- Length (waterline)76.4 m
- Beam15.2 m
- Draft5.61 m
◇Complement2MOD.2
- Total Complement276
- Officers20
◆Propulsion9MOD.9
- PropulsionSteam Turbine
- Arrangement (CODAG/COGAG…)2 × triple-expansion steam engines, 4 × fire-tube boilers, 2 × screw propellers
- Number of Engines4
- Shaft Power3,559 kW
- Shafts / Screws2
- Top Speed15 kn
- Cruise Speed10 kn
- Range2,290
- Nuclear-PoweredNo
▤Gun Armament4MOD.4
- Main Gun3 × 24 cm K L/35
- Main Gun Calibre240 mm
- Main Gun Count3
- Secondary Guns10 × 8.8 cm SK L/30
⬢Missile Armament3MOD.3
▲Underwater Warfare4MOD.4
- Torpedo Tubes3
- ASW CapabilityNo
- Hull-Mounted SonarNo
- Towed Array SonarNo
◎Aviation3MOD.3
◈Sensors & Combat Systems3MOD.3
▣Survivability5MOD.5
- CBRN CitadelNo
- DegaussingNo
- Hull Materialsteel
- Stealth ShapingNo
- Automated Damage ControlNo
◇Fleet Status8MOD.8
- Completed2
- Active0
- Under Construction0
- Planned2
- Cancelled0
- Lost1
- Retired1
- Preserved0
◆Armour3MOD.3
- ArmourBelt: 240 mm, Deck: 70 mm, Conning tower: 120 mm
- Belt Armour240 mm
- Deck Armour70 mm
03 / History
SERVICE LIFESPANRetired
- 1893Production started
- 1896Production ended
- 1914First deployment: World War I
133
years in service
3
years in production
2
units produced
0
countries operating
ⓘ 2 countries retired it.
