01 / Overview
10.5 cm leFH 18M
Category
Country
Prime contractor
Production
1941–1945
Operators
💰 PERFORMANCE / PRICE ASSESSMENT Methodology ↗
TOWED ARTILLERY & MORTARS · WORLD WAR II
3
PERFORMANCE/PRICE
78
UNIT COST (2025 USD)
—
ⓘ Performance/Price and MASS score are computed across all units in the towed artillery & mortars category, regardless of era.
02 / Specs & Design
◎General4MOD.4
- Service Entry Year1941
- Combat Weight1,985 kg
- Carriage TypeSplit Trail
- In ServiceYes
◈Ordnance7MOD.7
- Calibre105 mm
- Barrel Length (calibres)28
- Ordnance TypeSeparate QF 105 x 155mm R
- Breech TypeSliding Block
- Recoil SystemHydro-Pneumatic
- Muzzle BrakeYes
- Bore EvacuatorNo
▣Performance5MOD.5
- Maximum Range (standard)12.325 km
- Muzzle Velocity540 m/s
- Rate of Fire (sustained)4
- Elevation-6° 30' to +40° 30'
- Traverse56°
◇Ammunition5MOD.5
- Projectile Weight14.81 kg
- Ammunition TypesHE, AP
- Charge Zones6
- HE RoundYes
- Precision-Guided RoundNo
◆Fire Control5MOD.5
▤Mobility5MOD.5
- Self-PropelledNo
- Prime Moverhorse or vehicle
- Shoot-and-ScootNo
- AutoloaderNo
- Protected Crew CabNo
⬢Dimensions1MOD.1
- Length3.271 m
▲Production1MOD.1
- Production Start1,941 year
◎Self-Propelled Chassis1MOD.1
03 / History
SERVICE LIFESPANStill in Service
- 1939First deployment: World War II
- 1941Production started
- 1945Production ended
85
years in service
4
years in production
2
countries operating
ⓘ The producing country still actively operates it. 3 countries retired it.
04 / Variants
▚ WEAPON FAMILY
05 / Operators
Operator Countries5country
10.5 cm leFH 18MSALES4records
Finland
Portugal
Syria
Serbiaⓘ "Present Value" is an estimated amount adjusted for inflation.
06 / MASS Score
TOWED ARTILLERY & MORTARS RANKING Towed Artillery & Mortars · World War II
MASS RANKINGSMASS ↗
49TOWED ARTILLERY & MORTARS3WORLD WAR II · TOWED ARTILLERY & MORTARS292GERMANY · ALL WEAPONS152PERFORMANCE/PRICE · TOWED ARTILLERY & MORTARS
ⓘ Rankings are within theTowed Artillery & Mortarscategory.
📖 TERMS ON THIS PAGE5terms
High Explosive (HE) round: an artillery or mortar projectile containing explosive filler designed to inflict damage through blast and fragmentation effects.
Recoil system using a combination of liquid and compressed gas to absorb and return energy from firing.
A device attached to a firearm's muzzle to redirect propellant gases, reducing recoil and muzzle rise during firing.
A breech mechanism in artillery where a solid block slides horizontally to open and close the breech for loading.
A towed artillery carriage configuration where the gun is transported with its two wheels separated, allowing for easier deployment and lower profile when in firing position.
These terms are listed automatically because they appear on this page.full encyclopedia →
