Data Quality88%
MASS(Military Archive Scoring System)
ⓘ Regardless of era, the same scoring system applies to all units in the tanks category.
01 / Overview
Panzer 38(t)B
Category
Country
Prime contractor
Production
1939–1942
Quantity
1,414
Operators
💰 PERFORMANCE / PRICE ASSESSMENT Methodology ↗
ⓘ Performance/Price and MASS score are computed across all units in the tanks category, regardless of era.
02 / Specs & Design
◎General5MOD.5
- Tank ClassificationLight Tank
- GenerationWW2
- Combat Weight9.5 t
- Crew Size4
- Service Entry Year1939
◈Firepower3MOD.3
- Main Gun Calibre37 mm
- Main Gun TypeRifled
- Main Gun Length (Calibres)48
▣Protection1MOD.1
- Armour TypeRiveted Steel
◇Mobility9MOD.9
- Engine Power123 hp
- Power-to-Weight Ratio13 hp/t
- Fuel TypePetrol
- Transmission TypeManual
- Suspension TypeLeaf Spring
- Max Road Speed42 km/h
- Max Off-Road Speed15 km/h
- Operational Range (Road)250 km
- Fording Depth0.9 m
◆Dimensions4MOD.4
- Length (Hull)4.61 m
- Width2.14 m
- Height2.4 m
- Ground Clearance0.4 m
▤Electronics & Optics1MOD.1
- FCS GenerationManual Optical
⬢Production & Service3MOD.3
- Years in Production4 year
- Current Service StatusRetired
- Notable Variants Count13
03 / History
SERVICE LIFESPANRetired
- 1939Production started
- 1942Production ended
87
years in service
3
years in production
1,414
units produced
0
countries operating
ⓘ 6 countries retired it.
04 / Operators
Operator Countries6country
Panzer 38(t)BSALES1records
| Year | Buyer | Quantity | Amount | Present Value (2025) |
|---|---|---|---|---|
| — |  Germany | 1,414 | — | — |
ⓘ "Present Value" is an estimated amount adjusted for inflation.
05 / MASS Score
TANKS RANKING Tanks · World War II
MASS RANKINGSMASS ↗
ⓘ Rankings are within theTankscategory.
📖 TERMS ON THIS PAGE7terms
A leaf spring is a simple spring made of one or more flexible metal strips bound together, used to absorb shocks and support weight in vehicle suspension, including some tanks.
A tank with reduced armor and weight for increased mobility.
Manual: a tank transmission in which the driver selects gear changes manually, typically using a clutch pedal and gear lever to engage gears.
A fire control system relying on optical sights and manual input for aiming and range estimation without computer assistance.
A refined product derived from crude oil, used as a fuel for internal combustion engines. A volatile, flammable liquid mixture of hydrocarbons.
A rifled gun has spiral grooves cut into its barrel.
Armour made from steel plates joined by rivets.
These terms are listed automatically because they appear on this page.full encyclopedia →
