Data Quality85%
MASS(Military Archive Scoring System)
ⓘ Regardless of era, the same scoring system applies to all units in the tanks category.
01 / Overview
Renault ZB
💰 PERFORMANCE / PRICE ASSESSMENT Methodology ↗
TANKS · INTERWAR PERIOD
82
PERFORMANCE/PRICE
40
UNIT COST (2025 USD)
—
ⓘ Performance/Price and MASS score are computed across all units in the tanks category, regardless of era.
02 / Specs & Design
◎General5MOD.5
- Tank ClassificationLight Tank
- GenerationInterwar
- Combat Weight5.5 t
- Crew Size2
- Service Entry Year1933
◈Firepower9MOD.9
- Main Gun Calibre37 mm
- Main Gun TypeRifled
- Muzzle Velocity (Max)600 m/s
- Effective Range (Main Gun)800 m
- Can Fire APFSDSNo
- Can Fire HEATNo
- Can Fire HE-FragYes
- Can Fire ATGMNo
- Coaxial / Secondary MG Count0
▣Protection8MOD.8
- Armour TypeRiveted Steel
- Hull Front Thickness (Max)15 mm
- Turret Front Thickness (Max)15 mm
- Frontal RHA Equivalent (KE)15 mm
- Has ERANo
- Has APSNo
- NBC ProtectionNo
- Smoke GrenadesNo
◇Mobility8MOD.8
- Engine Power60 hp
- Power-to-Weight Ratio10.9 hp/t
- Fuel TypePetrol
- Transmission TypeManual
- Suspension TypeLeaf Spring
- Max Road Speed30 km/h
- Max Off-Road Speed15 km/h
- Operational Range (Road)150 km
◆Dimensions3MOD.3
- Length (Hull)4.5 m
- Width2.2 m
- Height2.1 m
▤Electronics & Optics8MOD.8
⬢Amphibious & Special3MOD.3
▲Production & Service2MOD.2
- Years in Production2 year
- Current Service StatusRetired
03 / History
SERVICE LIFESPANRetired
- 1935Production started
- 1938Production ended
91
years in service
3
years in production
0
countries operating
ⓘ 2 countries retired it.
05 / MASS Score
TANKS RANKING Tanks · Interwar Period
MASS RANKINGSMASS ↗
ⓘ Rankings are within theTankscategory.
📖 TERMS ON THIS PAGE8terms
High-Explosive Fragmentation: ammunition that explodes on impact, releasing fragments.
A leaf spring is a simple spring made of one or more flexible metal strips bound together, used to absorb shocks and support weight in vehicle suspension, including some tanks.
A tank with reduced armor and weight for increased mobility.
Manual: a tank transmission in which the driver selects gear changes manually, typically using a clutch pedal and gear lever to engage gears.
A refined product derived from crude oil, used as a fuel for internal combustion engines. A volatile, flammable liquid mixture of hydrocarbons.
A rifled gun has spiral grooves cut into its barrel.
Armour made from steel plates joined by rivets.
