01 / Overview
T20 Medium Tank
Category
Country
Prime contractor
Production
1943–1944
Quantity
20
Operators
💰 PERFORMANCE / PRICE ASSESSMENT Methodology ↗
ⓘ Performance/Price and MASS score are computed across all units in the tanks category, regardless of era.
02 / Specs & Design
◎General4MOD.4
- Tank ClassificationMedium Tank
- GenerationWW2
- Combat Weight29.83 t
- Crew Size5
◈Firepower2MOD.2
- Main Gun Calibre76 mm
- Main Gun TypeRifled
▣Protection2MOD.2
- Armour TypeWelded Rolled Homogeneous Armour (RHA)
- Hull Front Thickness (Max)62 mm
◇Mobility7MOD.7
- Engine Power514 hp
- Power-to-Weight Ratio17.26 hp/t
- Fuel TypePetrol
- Transmission TypeManual
- Suspension TypeVolute Spring
- Max Road Speed40 km/h
- Operational Range (Road)160 km
◆Dimensions3MOD.3
- Length (Hull)5.7 m
- Width3 m
- Height2.44 m
▤Electronics & Optics1MOD.1
- FCS GenerationNone
⬢Production & Service1MOD.1
- Current Service StatusPrototype Only
03 / History
SERVICE LIFESPANRetired
- 1939First deployment: World War II
- 1943Production started
- 1944Production ended
83
years in service
1
years in production
20
units produced
0
countries operating
ⓘ 1 countries retired it.
05 / MASS Score
TANKS RANKING Tanks · World War II
MASS RANKINGSMASS ↗
ⓘ Rankings are within theTankscategory.
📖 TERMS ON THIS PAGE7terms
Manual: a tank transmission in which the driver selects gear changes manually, typically using a clutch pedal and gear lever to engage gears.
A tank with medium weight and armor, balancing mobility and firepower.
A refined product derived from crude oil, used as a fuel for internal combustion engines. A volatile, flammable liquid mixture of hydrocarbons.
A rifled gun has spiral grooves cut into its barrel.
A volute spring is a conical coil compression spring whose coils increase in diameter, used in some tank suspension systems to provide progressive resistance.
Armour made by welding and rolling homogeneous steel plates.
These terms are listed automatically because they appear on this page.full encyclopedia →
